BSW 3in1 400W CMY

Specification

SOURCE

Engine 400W LED module

8000K High Color Temperature, sharper and more professional stage beams

50,000 Hours Lifespan, long-lasting and stable performance

FUNCTION

BSW ( Beam Spot Wash) 3-in-1 Hybrid

Two Prism (6+8)

9 dichroic Colors, halfcolor and rainbow effect

12 fixed Gobos+open

7 Interchangeable / Rotating Gobos (Rotating in both directions at variable speed)

Color mixing system: linear CMY+CTO color mixing system

*Beam and Spot zoom angle: 4-35 degrees

0-100% linear Dimming

Linear motorized Focus

Linear Frost, awesome wash effect

Variable from 1-25 flashes or random strobe

3 Phase Motor on Pan/Tilt ( Ultra Fast, precise silent movement)

Extremly quiet motors and fast, stable

Display mode: LCD display, key + touch dual operation mode

High-speed strobe: 0-30 times/sec.

Adjustable speed strobe effect. Strobe macro function.

CONTROL AND PROGRAMMING

With RDM function, online software upgrade is available, dial address code

Color mixing system: linear CMY+CTO color mixing system

Macro function: console reset function, self-propelled mode, master-slave mode

Cooling method: Adopt axial fan to enhance cooling

Safety device: with electronic temperature control overheating protection,electronic temperature control automatic power-off protection when the overheating system fails

Appearance material: high temperature resistant plastic

CONTROL & CONNECTIONS

(2) DMX Channel Modes (21/23 channels)

Intelligent LCD Display

3-pin DMX In/Out

PowerCON Power In/Out

DMX512, Auto run, Sound, Master/Slave

THERMAL & ELECTRICAL

430W max Power Consumption

Input voltage: 100-240V AC/50-60 Hz

APPROVALS / RATINGS

CE | RoHs Compliant | IP20

SIZE / WEIGHT

15" (380mm) Length

10.6" (270mm) Width

25.6" (650mm) Height

57 lbs (26 kg) Weight
